Trouble Shooting:-

Step

Checks

IF YES

IF NO

Check whether the EMS ECU is receiving supply and

Ground

Go to step 2

Rectify wiring

harness

connections as

per schematic

Check whether the battery is healthy

Go to step 3

Repair Battery

If fault still persists

Replace EMS ECU

Repeat above

procedure for

reconfirmation

DTC’s confirmation:-

After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before

handing over to customer.

Replace EMS ECU and check whether the fault is rectified or not.
