U0423-81:- Invalid Data received from Instrument Panel Cluster Module- Invalid serial data received
Overview:
ISO Code
U0423-81
Customer Symptom
None
Fault Effects (On Vehicle)
Vehicle speed valid information won’t be available to EMS.
Hence EMS features GSD, GSI in vehicle will work in default
condition.
Lamp Status (If Any)
NA
Fault Detection Condition
Incorrect data received from Instrument Panel Cluster control
module
Normal Operating Condition
Error free communication with ECM and IPC Control Module.
Probable Trouble Area
Incorrect data received from IPC Module
Healing Condition
Clearing of the functional failures in the IPC Module.
