OSPREY- Application
DTC Troubleshooting Data
Version: 4.0
Date: 10-02-2017
Prepared by: Mithipati Prasad
Checked by: G S Raju / Senthilnathan S
Page: 197 of 654
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:
Step Checks
IF YES
IF NO
1
Check the Injector Connector for any damage
Replace connector
Go to step 2
2.
Is there any dirt or Rust on Connector
Remove the
connector and clean
it and refit it tightly
Go to Step 3
3
Perform the Injector cylinder 1 actuator test. Is the test
successful
Go to step 4
Some problem in
Wiring harness
connections
4.
Check the continuity between the EMS ecu pin 6 and
connector pin 2. Check the continuity between the injector
connector pin 1 and EMS ECU pin 7. Is continuity test
successful
Go to step 5
Establish continuity
by rectifying wiring
harness
connections as per
the schematic.
5.
Is the Injector connector pin 1 short circuited to
battery/Ground? Perform this test by keeping Ignition Off.
Go to Step 6
Rectify Wiring
Harness
connections as per
the schematic
6.
Check whether the Injector LSD pin 6 is Short circuited to
Ground/open circuited
Rectify Wiring
Harness
connections as per
the schematic
Go to step 7
7
Is the resistance between the Injector 1 and EMS ecu less
than 1 ohm?
Go to Step 8
Replace the
Injector 1 wiring
Harness
8. Is the resistance across the injector terminals less than
12.25 ohms?
Go to Step 9
Replace the
Injector of cylinder
1
9.
Check whether any injector pins are backed out at ECU
Connector or Injector connector
Rectify the
connections
Go to Step 10
10 Is there any physical damage to Injector connector / ECU
Connector
Replace the
respective
connectors
Go to step 11
11 If the fault still persists
Call Hotline
Repeat the above
procedure for
reconfirmation
DTC’s confirmation (checks before handing over vehicle to customer):
x
Please fit the injector with its connector on wiring harness and remove ECU connector and check for continuity
between injector and the ECU connector.
x
Perform actuator test for the corresponding injector.
x
Check the errors at Ignition ON, engine running @ Idle & Fly up with different vehicle speeds also
x
If error present, then rectify the errors.
x
Confirm that there is no error logged in EMS before handing over vehicle to customer
