Trouble Shooting:
Step Checks
IF YES
IF NO
1.
Are Relay Contacts weld?
Replace the Relay
Go to Step 2
2.
Is there wiring harness electrical continuity between
ECU pin 60 & Fan relay pin X. Also Check continuity
between the Main Relay supply and the Fan relay Coil
pin X and Battery Supply to Relay contact pin X.
Go to Step 3
Establish continuity
by rectifying
harness
connections as per
the circuit
schematic
3. Are there any pins damaged at EMS ecu Connector
Replace the connector
or wiring harness
Go to step 4
4
Are there any pins backed out from the EMS ecu
Connector
Rectify/Replace
Connectors
Go to Step 5
5
Is relay getting Supply at its pin XX
Go to Step 6
Repair the harness
as per the
schematic
6
Is Fan Relay control Pin 60, Short circuited to
GND/Battery
Repair the harness as
per the schematic
Go to Step 7
7
Is fan Properly Working or stalled
Rectify / Replace Fan
Go to Step 8
8
Fault Still Persists?
Replace relay and then
if Fault still persists then
Call Hot Line
Follow the steps
again for
reconfirmation
DTC’s confirmation (checks before handing over vehicle to customer):
x
Perform Actuator test for low speed fan and visually check that fan is operating.
x
When vehicle is soaked for 8 hours and Engine is cranked keeping AC off then Cooling fans will be in Off
condition.
x
If any faults present, then rectify the faults. Confirm that there are no faults logged by EMS before handing over
the vehicle to customer.
