Key off and wait for 30 sec and key on, check for reappearance of the DTC.
x
Check faults related to SPC / SPCI disable: P0115, P0112, P0113, P1171, P1172, P1173, P1174, P0237, P0238,
P1235, P1236, P0263, P0272, P0266, P0269, P0201, P0202, P0203, P0204, P1201, P1202, P1203, P1204,
P0192, P0193, P0191, P0194, P0500. If present, rectify them by following their rectification procedure.
Trouble Shooting:
Step Checks
IF YES
IF NO
1
Cross check I3C values of Injector cylinder 2 (20-digit alpha
numeric value printed on the injector) against I3C value
feed fed in the ECU. Are they matching?
Go to next step
Re-write the I3C
value of Injector 1
as per the sticker
on Injector 1.
2
Perform the Injector cylinder 2 actuator test. Is the test
successful
Go to step 3
Some problem in
Wiring harness
connections.
Rectify them as per
the schematic
3
Check faults related to SPC / SPCI disable: P0115, P0112,
P0113, P1171, P1172, P1173, P1174, P0237, P0238,
P1235, P1236, P0263, P0272, P0266, P0269, P0201,
P0202, P0203, P0204, P1201, P1202, P1203, P1204,
P0192, P0193, P0191, P0194, P0500. Are they present?
Rectify them by
following their
rectification
procedure
Go to Next Step
4
Perform the SPCS learning of Injectors.
Go to Step 5
-
5
Is there any physical damage to Injector connector / ECU
Connector
Replace the
respective
connectors
Go to next step
6
If the fault still persists
Call Hot Line
Repeat the above
procedure for
reconfirmation
DTC’s confirmation (checks before handing over vehicle to customer):
x
Check the errors at Ignition ON, engine running @ Idle & Fly up with different vehicle speeds.
x
Confirm that there are no errors logged by EMS before handing over the vehicle back to customer
