NEXON DIAGNOSTIC MANUAL

yϭϬϰ KƐƉƌĞǇ /ŶƐƚƌƵŵĞŶƚ ůƵƐƚĞƌ

d dƌŽƵďůĞƐŚŽŽƚŝŶŐ ĂƚĂ

sĞƌƐŝŽŶ͗ ϭ͘ϯ

ĂƚĞ͗ ϮϬͲDĂƌĐŚͲϭϳ

Author: Balaji / Amar /

Nitin / Umapathi /

Deepak

Page: 64 of 138

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

DTC’s confirmation:-

After rectification, ensure the following points before handing over the system to the customer.

1. Check the Illumination o/p

the changing the illumination i/p settings through display.

2. Check the Illumination o/p signal status in vehicle driving condition also.

Circuit Schematic Diagram:-

Component Location & Image:-

N/A

Connector View & Information:-

Batt Gnd Pinno.J1-10

Illumination o/p (PinNo.J1-9)
