B1C4B-13: LVDS connector - circuit open
Overview:
Write up for the Related Sensor/Actuator or system:-
LVDS Connector – It is used as an interface between silver box and Display component
Pre-Check Points:
NO
Trouble Shooting:-
Below given flowcharts guides to troubleshoot the fault:
ISO Code
B1C4B-13
Customer Symptom
User is unable to see visual information on Display
Fault Effects (On Vehicle)
No
Lamp Status (If Any)
No
Fault Detection Condition
1. User is unable to see visual information on
Display.
2. This DTC gets logged when connection between
infotainment silver box and Display is Open.
Normal Operating Condition
User is able to see visual feedback on Display
Probable Trouble Area
x
Wiring harness between silver box and Display.
x
Silver box connector and its connector terminals
x
Display connector and its terminals
x
Intermittent connector and their terminals
Healing Condition
None
