NEXON DIAGNOSTIC MANUAL

Vehicle Platform: OSPREY

ECU Name: Hella Body Control Module (BCM) DTC

Troubleshooting Data

Version: 1.1

Date: 03 Mar 2017

Author: Body CoC

Page: 57 of 784

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

After rectification, ensure the following points using TML diagnostic tool before handing over to customer.

a) Check whether VICM ECU is communicating with diagnostic Tool or not.

b) DTC should not be present in ECU memory.

Circuit Schematic

Diagram:-N.A

Component Location & Image:- N.A

Connector Location: N.A

Connector View & Information: - N.A

VICM ECU Side Connector:

Inspection Method: - N.A

HU ECU Pin assignment:-

Description

ECU pin

CAN_H

CAN_L

Battery

1,7

Ignition input

Battery ground
