Trouble Shooting:-
Step Checks
IF YES
IF NO
1.
Is there any rust/oxidization observed on Sensor Terminals Clean the Rust or
repair or replace
Go to Step 2
2.
Is there wiring harness electrical continuity between
ECUpins 121,138, 105 &Accelerator pedal Sensor 1
Sensor connector pins 4,2,3.
Go to Step 3
Establish continuity
by rectifying
harness
connections as per
the Circuit
schematic
3. Are there any pins damaged at Sensor/EMS ECU
Connector
Replace the
connector or wiring
harness
Go to step 4
4
Are there any pins backed out from the Sensor/EMS ECU
Connector
Rectify/Replace
Connectors
Go to Step 5
5
Is Sensor Supply Pin 138 Short Circuited to GND/Battery.
Repair the harness
as per the schematic Go to step 6
6
Is Sensor Signal Pin 121 Short Circuited to GND/Battery?.
Repair the harness
as per the schematic Go to Step 7
7
Is Sensor physically Damaged
Replace Sensor
Go to Step 8
8
Fault Still Persists?
Replcae Sensor and
then Fault still
persists then
Replace EMS ECU
Follow the steps
again for
reconfirmation
DTC’s confirmation:-
After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before
handing over to customer.
Press the Accelerator pedal Sensor in incremental steps and check the Vehicle parameter – Accelerator pedal Sensor
1 (in percentage) is varying incrementally.
