Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.1
Date: 03 Mar 2017
Author: Body CoC
Page: 305 of 784
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
DTC’s confirmation:-
After rectification, ensure the following points by using TML diagnostic tool before handing over to customer.
a) Check DTC B2252 – 62 is not logged
b) Turn left and turn right indicators are working properly.
Circuit Schematic Diagram:-
Note:
For detailed information please refer latest BCM wiring harness schematic.
Connector View & Information: -
Please refer respective BCM Drawing for BCM connector PIN details and combi switch drawing for left and
right turn indicator PIN details.
Inspection Method: -
NA
