Trouble Shooting:-

Step Checks

IF YES

IF NO

Is there any rust/oxidization observed on Sensor Terminals Clean the Rust or

repair or replace

Go to Step 2

Is there wiring harness electrical continuity between

ECUpins 223,203, 220 &Throttle Position Sensor connector

pins 3, 6, 5?

Go to Step 3

Establish continuity

by rectifying

harness

connections as per

the Circuit

schematic

3. Are there any pins damaged at Sensor/EMS ECU

Connector

Replace the

connector or wiring

harness

Go to step 4

Are there any pins backed out from the Sensor/EMS ECU

Connector

Rectify/Replace

Connectors

Go to Step 5

Is Sensor Supply Pin 223 Short Circuited to GND/Battery or

Open?

Repair the harness

as per the schematic Go to step 6

Is Sensor Signal Pin 220 Short Circuited to ground or Open

Circuited?

Repair the harness

as per the schematic Go to Step 7

Is Sensor physically Damaged

Replace Sensor

Go to Step 8

Fault Still Persists?

Replcae Sensor and

then Fault still

persists then

Replace EMS ECU

Follow the steps

again for

reconfirmation

DTC’s confirmation:-

After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before

handing over to customer.

Pls. perform the Throttle Actuator IO Control test. IF test is successful then the fault rectification is confirmed.
