C0034-14 - Right Front Wheel Speed Sensor- Circuit short to Ground or open
Overview
ISO Code
C0034-14
Customer Symptom
Warning Light Displayed
Fault Effects (On Vehicle)
x
ABS is not available.
x
EBD is available.
Lamp Status (If Any)
Warning Light Displayed
Fault Detection Condition
x
FR WSS is not functional
Normal Operating Condition
ABS is functional between 10 to 16V
Probable Trouble Area
x
Short circuit of the WSS_FR supply/signal line to
GND / interruption.
x
Defective wheel speed sensor
Healing Condition
NA
Component Details
Wheel Speed Sensor - A wheel speed sensor is part of the Anti-lock Brake System (ABS). It is located on the
tires. The job of the wheel speed sensor is to constantly monitor and report the rotational speed of each tire to
the ABS control module.
Preliminary Checks
Check short circuit of the WSS_FR supply/signal line (Pin no.4 of below shown connector) to GND (Visually).
