ABS - DTC Troubleshooting Data
(Bolt, Zest, Tiago, Pelican, Nexon & Tigor)
Version: 1.4
Date: 21 April 2017
Author: ERC - Chassis E&E
Page 77 of 166
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting
START
IS DTC
PRESENT?
STOP
NO
1. CONNECT THE TML DIAGNOSTIC TOOL.
2. TURN THE IGNITION ON.
3. CHECK THE STATUS OF DTC’s (MENORIZED/CURRENT)
4. RECORD THE DTC AND CLEAR.
5. TURN IGNITION OFF & ON.
6. VERIFY IF DTC C131E-01 IS PRESENT
A
CHECK ALL WHEEL SPEED SENSORS
(WSS)
ANY
DEFECTIVE
WSS?
STOP
NO
YES
YES
EXCHANGE DEFECTIVE WHEEL SPEED
SENSORS (WSS)
1. CHECK TIRE/RIM SIZE AS PER VARIANT
2. ALL 4 TIRES SHOULD BE OF SAME SIZE
