NEXON DIAGNOSTIC MANUAL

ABS - DTC Troubleshooting Data

(Bolt, Zest, Tiago, Pelican, Nexon & Tigor)

Version: 1.4

Date: 21 April 2017

Author: ERC - Chassis E&E

Page 97 of 166

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

C001D-04 - Right Rear Outlet Control-System internal Failure

Overview

ISO Code

C001D-04

Customer Symptom

Warning Light Displayed

Fault Effects (On Vehicle)

None of the functionalities of ABS ECU are available

Lamp Status (If Any)

Warning Light Displayed

Fault Detection Condition

Any type of hydraulic or electric failure in Right Rear Outlet

Valve circuit

Normal Operating Condition

ABS is functional between 10 to 16V

Probable Trouble Area

Failure in Right Rear Outlet Valve circuit (Hydraulic/Electric)

Healing Condition

Component Details -

Preliminary Checks -
