ABS - DTC Troubleshooting Data
(Bolt, Zest, Tiago, Pelican, Nexon & Tigor)
Version: 1.4
Date: 21 April 2017
Author: ERC - Chassis E&E
Page 140 of 166
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
U3006-1C - Control Module Input Power "A"-Circuit Voltage out of Range
Overview
ISO Code
U3006-1C
Customer Symptom
Warning Light Displayed
Fault Effects (On Vehicle)
x
None of the functionalities of ABS ECU are available.
Lamp Status (If Any)
Warning Light Displayed
Fault Detection Condition
Normal Operating Condition
ABS is functional between 10 to 16V
Probable Trouble Area
x
Fuse of the Voltage supply (UB_VR) defective /
Voltage supply line has an interruption.
x
Connection of the ground line (Car body) or the
contact points (Plug-in connectors) are corroded
(Voltage drop)
x
Battery discharged or insufficient charging capacity.
Healing Condition
NA
Component Details -
NA
Preliminary Checks
x
Examine the fuse of the Voltage supply (UB_VR – 25 amp) and exchange if defective.
x
Remove voltage drop at contact points if any
