If the pump turns ON but no Pressure build
up:
1> Check Kit oil, refill if necessary
2> Check for oil leakage / damage to
hydraulic pipes.
3> Replace the TCU
4> Replace the Kit
DTC’s confirmation:-
After rectification, clear all DTC’s and ensure the following points by referring TCU parameters using TML diagnostic tool
before handing over to customer.
Drive the vehicle through all gears in both Automatic and Manual modes
Ensure no DTC is active and Transmission Fault Lamp is OFF.
Circuit Schematic Diagram:
