NEXON AMT
DTC Troubleshooting Guide
Version: 2.0
Date: 24-01-2018
Author: Suraj/Anupama
Page: 333 of 434
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Circuit Schematic Diagram:
NA
Component Location & Image:-
NA
Connector Location: -
1) Inter-harness connector is In Engine Compartment, below battery and 2) TCU connector is below Glove box.
Connector View & Information: -
Inter wiring harness connector of AMT KIT
Inspection Method: -
