4
Fault Still Persists?
Go to Step 5
Follow the steps
again for
reconfirmation
5
Unmount the TCU from the valve body and
investigate any loose contacts/damaged
valves/ sensor connectors. Any problem is
detected?
Replace TCU/Valve body/kit
Replace the TCU
and if problem
persists replace the
kit
DTC’s confirmation:-
After rectification, clear all DTC’s and ensure the following points by referring TCU parameters using TML diagnostic tool
before handing over to customer.
Drive the vehicle through all gears in both Automatic and Manual modes
Ensure no DTC is active and Transmission Fault Lamp is OFF.
Circuit Schematic Diagram:
Component Location & Image:-
Connector Location: -
Connector View & Information: -
Inspection Method: -
