DTC’s confirmation:-
After rectification, ensure the following points using TML diagnostic tool before handing over to customer.
b)
DTC should not be present in ECU memory.
Connector View & Information: -
DCS ECU side connector diagram
DCS ECU Pin assignment:-
Pin No.
Pin Name
Description
CAN_H
CAN High
CAN_L
CAN Low
Ign
Ignition
Vbat
Supply Voltage Battery
GND
Battery GND
