P0351-14: Ignition Coil “A” Primary Control Circuit High– Circuit Short to Ground or Open
Overview:
ISO Code
P0351-14
Customer Symptom
1. Engine shuts off and can be only started after Ignition switch resetting or
coil has cooled down.
2. Misfires may happen
Fault Effects (On Vehicle)
1. Engine shuts off and can be only started after Ignition switch resetting or
coil has cooled down.
2. Misfires may happen
3. Igniton failure may lead to misfire & stall the engine.
Lamp Status (If Any)
MIL ON after 1 drive cycle
Fault Detection Condition
This fault gets logged when the Ignition coil A control pin of EMS ECU is Open
Circuited
Normal Operating Condition
Healthy wiring harness connections between Ignition Coil A and EMS ECU
Probable Trouble Area
Wiring Harness connections, Ignition coil A
Healing Condition
After 3 driving cycles
Fault permanent deletion
1. Clear DTC Command form Scan tool
2. Stack Over Flow.
3. 40 warm up cycles.
4. ECU Flashing.
5. ECU Power-Fail.
Component Details:
An
ignition coil
(also called a
spark coil
) is an induction coil in an automobile's ignition system which transforms the
battery's low voltage to the thousands of volts needed to create an electric spark in the spark plugs to ignite the fuel.
The wire that goes from the ignition coil to the distributor and the high voltage wires that go from the distributor to each
of the spark plugs are called spark plug wires or high tension leads.
Preliminary Checks:
1) Loose/ Damaged Connections between Ignition coil A and EMS ECU.
2) Check for back out of pins at both Ignition Coil connector and ECU connector.
3) Check for damage of pins at both Ignition Coil connector and ECU connector.
