Trouble Shooting:-
Step Checks
IF YES
IF NO
1.
Are Relay Contacts weld / Stuck Open
Replace the Relay
Go to Step 2
2.
Is there wiring harness electrical continuity between
ECUpin 113&Pump relay pin
X
. Also Check continuity
between the Main Relay supply and the Pump relay pin
X
.
Also check continuity from Pump Relay pin
X
to GND.
Go to Step 3
Establish continuity
by rectifying
harness
connections as per
the circuit
schematic
3. Are there any pins damaged at EMS ECU Connector
Replace the
connector or wiring
harness
Go to step 4
4
Are there any pins backed out from the EMS ECU
Connector
Rectify/Replace
Connectors
Go to Step 5
5
Is relay getting Supply at its pin
XX
Go to Step 6
Repair the harness
as per the
schematic
6
Is Pump Relay control Pin 113, Short circuited to GND
Repair the harness
as per the schematic Go to Step 7
7
Is Fuel Pump Working or stalled
Rectify / Replace
Pump
Go to Step 8
8
Fault Still Persists?
Replace relay and
then if Fault still
persists then
Replace EMS ECU
Follow the steps
again for
reconfirmation
DTC’s confirmation:-
After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before
handing over to customer.
Perform the Actuator test for Fuel Pump. It should be successful.
