P0692-12: A/C Fan 1 Control Circuit High– Circuit Short to Battery
Overview:
ISO Code
P0692-12
Customer Symptom
1. A/C will not work, nothing to do with limphome
Fault Effects (On Vehicle)
1. A/C will not work
Lamp Status (If Any)
CE lamp ON after 1 drive cycle
Fault Detection Condition
This fault gets logged if the Low speed fan control pin of EMS ECU is short
Circuited to Battery
Normal Operating Condition
Healthy Wiring Harness connections between A/C Fan relay and EMS ECU,
Relay Fully Operational, Healthy Wiring Harness connections from Relay to
Main Relay supply and Ground.
Probable Trouble Area
Improper Wiring Harness Connections, faulty Relay, Faulty radiator fan
Healing Condition
Ignition key on and 1 drive cycles after fault rectification
Fault permanent deletion
1. Clear DTC Command form Scan tool
2. Stack Over Flow.3. 40 warm up cycles.4. ECU Flashing.5. ECU Power-Fail
Component Details:
Radiator fan is driven by EMS ECU via a relay, Fan will be ON, when the EMS ECU energizes the coil of fan relay.
Preliminary Checks:
1) Loose/ Damaged Connections between Fan Relay and EMS ECU.
2) Loose/ Damaged Connections between Fan Relay and Battery supply and Main Relay Supply.
3) Check for back out of pins at ECU connector.
4) Check for damage of pins at ECU connector.
5) Check the continuity from Relay to the ECU pin and from battery / Main Relay Supply to Fan Relay.
