P2101-64: Throttle Actuator Control Motor Circuit Range/Performance – Signal Plausibility Failure
Overview:
ISO Code
P2101-64
Customer Symptom
1)ETC Control will Not be active.
2)Vehicle /Engine speed will be limited for safety concerns
Fault Effects (On Vehicle)
1)ETC Control will Not be active.
2)Vehicle /Engine speed will be limited for safety concerns
Lamp Status (If Any)
MIL ON after 1 drive cycles
Fault Detection Condition
This fault gets logged if the throttle actuator motor Pin no 251 or Pin 252 gets
short Circuit to battery/Ground or Open Circuited.
Normal Operating Condition
Throttle actuator functions as per design
Probable Trouble Area
Throttle Actuator control motor ,wiring harness connections, EMS ECU
Healing Condition
After 3 drive cycles
Fault permanent deletion
1. Clear DTC Command form Scan tool
2. Stack Over Flow.
3. 40 warm up cycles.
4. ECU Flashing.
5. ECU Power-Fail
Component Details:
A DC motor drive is used to move the throttle valve over the complete movement range. The DC motor is directly
controlled by the ECU of the Gasoline engine. Throttle Valve H-bridge driver of EMS ECU provides bidirectional
control with active recirculation and over current detection.
Preliminary Checks:
1. Pls. check whether dust/mud/any particle is blocking throttle valve.
2. Pls. check whether the throttle valve is stuck closed
3. Pls. check for any throttle body related faults and rectify those faults by following their rectification procedure.
