ECM ECU Pin assignment:-
Connector
No.
Pin No.
Pin Name
Description
Vehicle Connector-1
C1,32
CAN_H
CAN High
C1,44
CAN_L
CAN Low
C1,16
IGN
Ignition
C1,55;
C1,56
VBATT
Supply Voltage Battery
C1,53;
C1,54
GND
Battery GND
