P0119: Coolant Temperature Fault – Gradient
Overview:
DTC Description as per ISO standard
Engine Coolant Temperature Sensor 1 Circuit Intermittent
ECU Pin Number
72
Customer Symptom
Power Loss
AC will be Off
Fans always running in High speed if Engine is running for certain
duration of time.
Fault Effects (On Vehicle)
Reduced torque Mode active.
Injector learning strategy is deactivated (MDP Updation is
deactivated).
System coolant temperature slowly moves to recovery value of 80
deg., This fault will also set P0115 - Coolant temp fault.
Lamp Status (If Any)
CE Lamp & MIL Lamp is on.
Fault Detection Condition (Root
cause)
This DTC gets logged if the rate of change of coolant temperature
crosses the threshold
Normal Operating Condition
No Faults related to coolant temperature sensor
Probable Trouble Area
Coolant temperature sensor, ECU, Grounding points, Wiring harness
Healing Condition
Clear the errors, Ignition OFF to ON, engine running for min 5deg
temperature rise
Component Details:
The temperature sensing circuit uses Thermistor that is sensitive to change in temperature. It has basically the NTC
(Negative Temperature Coefficient) means as the temperature increases, the resistance decreases. Based on the Engine
coolant temperature, EMS controls the Fuel Injection and cooling fan operation. Engine coolant temperature information
will also be displayed on the Instrument cluster.
Preliminary Checks:
x
Check whether the customer voice / view about the issue is matching with the fault effects mentioned above. If
yes, go ahead with next steps. If not, check for other DTC’s presence.
x
Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to
earlier issue closure.
x
Loose/ Damaged Connections between Sensor and EMS ECU.
x
Check for back out of pins at both Sensor connector and ECU connector.
x
Check for damage of pins at both sensor connector and ECU connector.
