P0122: Accelerator Pedal Sensor Track1 Fault Signal - Low
Overview:
DTC Description as per ISO standard
Throttle/Pedal Position Sensor/Switch “A” Circuit Low
ECU Pin Number
37, 78, 16
Customer Symptom
Engine Power Loss
Fault Effects (On Vehicle)
Reduced torque Mode will be activated
Pedal reduction (P1121 is set)
EGR is disabled.
EMS ecu will use the second Accelerator pedal track input for Engine
Control
Lamp Status (If Any)
CE Lamp is on
Fault Detection Condition
This DTC gets logged because of Track 1 counts read by the sensor is
less than lower threshold.
Normal Operating Condition
Diagnostic tool display the value of accelerator pedal pressed in % at
ignition ON condition
Probable Trouble Area
Accelerator Pedal sensor
Related wiring Harness, connector or terminals
ECU
Healing Condition
Rectify the error
Clear through diagnostic tool
Ignition OFF & ON
Component Details:
For safety reasons, the accelerator pedal sensor is equipped with 2 resistors (potentiometers) with varying operating
ranges (0.75
–
4.45 V and 0.38
–
2.23 V) and separate circuits. A potentiometer informally a pot, is a three- terminal
resistor with a sliding contact that forms an adjustable voltage divider. If only two terminals are used, one end and the
wiper, it acts as a variable resistor or rheostat. Based on the Accelerator pedal position, Engine will produce the driver
demanded torque based on the accelerator pedal position.
Preliminary Checks:
x
Check whether the customer voice / view about the issue is matching with the fault effects mentioned above. If
yes, go ahead with next steps. If
not, check for other DTC’s presence.
x
Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to
earlier issue closure.
x
Check for Reference voltage 2 fault (P0642, P0643) if present; Follow Reference voltage2(sensor supply
voltage2) check and rectification Procedure, to correct this fault before proceeding further
x
Check the pedal connector connected to the pedal sensor/ module.
x
Check sensor connections for rust dirt etc; clean the sensor connections and ensure proper fitment.
x
Check Intermediate connector; Remove Intermediate connector between EMS harness and vehicle wiring
harness. Check for terminal back out. Do necessary repairs, then reconnect and check the fault.
x
Visually check sensor; Replace sensor if damaged.
