P0192: Rail Pressure Fault Signal – Low

Overview:

DTC Description as per ISO standard

Fuel Rail Pressure Sensor “A” Circuit Low.

ECU Pin Number

Customer Symptom

Once the engine is started and running.

Engine vibrates and makes noise, Reduced torque mode activated/

vehicle lack performance.

Engine will stop after delay.

Fault Effects (On Vehicle)

Stops the Engine after few seconds. Disables the Pilot Injection,

RVD disable, EGR will be disabled,

Allows the IMV to operate without trim values, Deactivates the Leak

Detection test, Forces the IMV to open fully,

Limits the System Pressure demand to calibratable pressure in bar,

Deactivates the Rail pressure sensing/ Measurement,

Rail Pressure Build measurement is deactivated,

Disables the Rail pressure control fault detection

Limp Home Mode activated.

Lamp Status (If Any)

CE & MIL Lamp is on.

Fault Detection Condition (Root cause)

This DTC gets logged if the Rail pressure measured is lower than lower

threshold

Normal Operating Condition

Rail Pressure displayed on diagnostic tool shall vary if Accelerator pedal

is ramped from 0 to 100%

Probable Trouble Area

Rail pressure sensor, ECU, Wiring harness

Healing Condition

Clear the errors, Ignition OFF to ON, engine idle, fly-up and specially

vehicle running in different speed condition

Component Details:

Rail pressure sensor is a piezoelectric type one, which is used to measure the fuel pressure inside the Rail. It provides the

pressure in terms of voltage to the ECU. This rail possesses an under pressure supply of diesel fuel which is ready to be

used by the injectors. The drop of pressure in the rail is immediately signaled by the sensor to the engine control unit. This

is followed by the restoration of pressure in the pump. It is the engine control unit that controls the fuel supply of the rail

from a pump possessing very high pressure. This is done by using a valve for controlling the pressure of fuel.

Preliminary Checks

Check whether the customer voice / view about the issue is matching with the fault effects mentioned above. If

yes, go a

head with next steps. If not, check for other DTC’s presence.

Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to

earlier issue closure.

Check adequate fuel is available in the tank. Check there is no air entry in to the low pressure fuel line.

Check ECU pins and connector, replace if found defective.

Check HP circuit; refer HP circuit check and rectification procedure.

Check LP circuit; refer LP circuit check and rectification procedure.
