P0193: Rail Pressure Fault Signal – High

Overview:

DTC Description as per ISO standard

Fuel Rail Pressure Sensor “A” Circuit High.

ECU Pin Number

Customer Symptom

Once the engine is started and running - Engine vibrates and makes noise,

Reduced torque mode activated which will lead to Power loss

Engine will stop after delay.

Fault Effects (On Vehicle)

Stops the Engine after few seconds. Disables the Pilot Injection,

RVD disable, EGR will be disabled,

Allows the IMV to operate without trim values, Deactivates the Leak

Detection test, Forces the IMV to open fully,

Limits the System Pressure demand to calibratable pressure in bar,

Deactivates the Rail pressure sensing/ Measurement,

Rail Pressure Build measurement is deactivated,

Disables the Rail pressure control fault detection

Limp Home Mode activated.

Lamp Status (If Any)

CE & MIL Lamp is on.

Fault Detection Condition (Root

cause)

This DTC gets logged if the Rail pressure measured is greater than upper

threshold

Normal Operating Condition

Rail Pressure displayed on diagnostic tool shall vary if Accelerator pedal is

ramped from 0 to 100%

Probable Trouble Area

Rail pressure sensor, ECU, Wiring harness

Healing Condition

Clear the errors, Ignition OFF to ON, engine idle, fly-up and specially

vehicle running in different speed condition

Component Details:

Rail pressure sensor is a piezoelectric type one, which is used to measure the fuel pressure inside the Rail. It provides the

pressure in terms of voltage to the ECU. This rail possesses an under pressure supply of diesel fuel which is ready to be

used by the injectors. The drop of pressure in the rail is immediately signaled by the sensor to the engine control unit. This

is followed by the restoration of pressure in the pump. It is the engine control unit that controls the fuel supply of the rail

from a pump possessing very high pressure. This is done by using a valve for controlling the pressure of fuel.

Preliminary Checks

Check whether the customer voice / view about the issue is matching with the fault effects mentioned above. If

yes, go ahead with next steps. If not, check for other DTC’s presence.

Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to

earlier issue closure.

Check HP circuit; refer HP circuit check and rectification procedure.

Check LP circuit; refer LP circuit check and rectification procedure.

Check & Rectify the connector / Injector Harness continuity, connector oxidation etc
