OSPREY- Application

DTC Troubleshooting Data

Version: 4.0

Date: 10-02-2017

Prepared by: Mithipati Prasad

Checked by: G S Raju / Senthilnathan S

Page: 224 of 654

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

P0341: Cam Shaft Signal – Synchronization Fault

Overview:

DTC Description as per ISO standard

Camshaft Position Sensor “A” Circuit Range/

Performance

ECU Pin Number

34

Customer Symptom

Engine vibrations will be noticed at certain speeds if fault gets

detected during Engine running

Engine will not fire after fault detection.

Fault Effects (On Vehicle)

Engine vibrates at certain speeds if fault gets detected during Engine

running

EMS will disable engine start after fault detection.

Lamp Status (If Any)

CE lamp is on

Fault Detection Condition

This DTC gets logged if the ECU does not receive the cam sensor

signal within the defined window w.r.t crank signal ;(instead receives

it outside the window.)

If the cam movement is detected but the cam events are not in the

expected window position; if the rising and falling edge of the cam

flank is detected wrongly.

Normal Operating Condition

Diagnostic tool display the value of cam sensor status at idling

Probable Trouble Area

Camshaft sensor, Timing gear / belt btw Cam and crank shaft, ECU,

Grounding points, Wiring harness

Healing Condition

Clear the errors, Ignition OFF to ON

Component Details:

A typical Hall Effect Sensor has three wires or terminals: one for ground, one for supply or reference voltage and one for

the output signal. To produce an output signal, a Hall Effect Sensor must be supplied with a reference voltage. When a

metal / wheel passes through the air gap between the magnetic field (Magnet) and silicon chip (CAM sensor), it blocks the

magnetic field and causes the chip’s output voltage to suddenly drop to zero else the chip's output voltage is 4.7 Volts.

Preliminary Checks

x

Check whether the customer voice / view about the issue is matching with the fault effects mentioned above.

If yes, go ahead with next steps. If not, check for other DTC’s presence.

x

Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to

earlier issue closure.

x

Check sensor connections for rust dirt etc; Ensure clean connector pins and proper fitment.

x

Check cam shaft; Replace cam shaft if found damaged.

x

Check for timing gear is o.k. if found faulty replace it.

x

Visually check sensor. Check for metallic particles/burr in sensor tip; Clean the sensor tip and cam to remove

any foreign particle.

x

Check for crank signal also.
