P0645: A/C Clutch Relay Control Circuit - open circuit
Overview:
DTC Description as per ISO standard
A/C Clutch Relay Control Circuit
ECU Pin Number
48
Customer Symptom
AC Compressor will not be engaged irrespective of AC
Request.
Fault Effects (On Vehicle)
AC Compressor will not be engaged even if AC is requested
Lamp Status (If Any)
CE lamp is on
Fault Detection Condition
This fault gets logged if the AC Clutch control pin of EMS ECU
is Open circuited.
Normal Operating Condition
Healthy wiring harness connections between AC Relay and
EMS ECU
Probable Trouble Area
AC Clutch relay
Related wiring Harness, connector or terminals
ECU
Component Details:
AC Compressor has a magnetic Clutch; Coil of the magnetic clutch is energized by EMS ECU. After getting Energized,
Clutch engages the compressor to the EMS ECU.
Preliminary Checks:
x
Check whether the customer voice / view about the issue is matching with the fault effects mentioned above. If
yes, go ahead with next steps. If not, c
heck for other DTC’s presence.
x
Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to
earlier issue closure.
x
Loose/ Damaged Connections between AC Compressor Relay and EMS ECU.
x
Loose/ Damaged Connections between AC Compressor Relay and Battery supply or Ground.
x
Check for proper installation of AC relay in fuse box.
x
Check for damage of pins at ECU connector.
