Trouble Shooting:
Step Checks
IF YES
IF NO
1.
Check the CAN connections between FATC module and
CAN network.
Rectify connections
Go to next step
2
Fault still persists?
All hot line
Repeat above step
for re-confirmation
DTC’s confirmation:
After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before handing
over to customer.
x
Turn the Ignition OFF and then turn it ON. Recheck the fault, Fault shall not reappear.
