Component Location & Image:-
VSS power signal is connected to sensor which is mounted on Transmission base (in same VSS
connector).TBA
Connector View & Information:-
SpdSensPWRSig (Pinno.J1-3)
VSS Connector
Inspection Method:-
Check the VSS sensor power signal output voltage through multimeter.
Battery GND Pin no. 19
