Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.1
Date: 03 Mar 2017
Author: Body CoC
Page: 774 of 784
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
16
U3000 - 08
Control Module Bus Signal / Message Failure
78
Y
17
U1006 - 42
Control Module Internal general memory Failure
81
N
18
P0604 - 00
Internal Control Module Random Access
memory (RAM) Error
83
N
19
P0605 - 00
Internal Control Module Read Only memory
(ROM) Error
85
N
20
U1008 - 16
Control Module Input Power 1 circuit voltage
below threshold
87
N
21
U1008 - 17
Control Module Input Power 1 circuit voltage
above threshold
91
N
22
U1009 - 16
Control Module Input Power 2 circuit voltage
below threshold
95
N
23
U1009 - 17
Control Module Input Power 2 circuit voltage
above threshold
99
N
24
U100A - 16
Control Module Input Power 3 circuit voltage
below threshold
103
N
25
U100A - 17
Control Module Input Power 3 circuit voltage
above threshold
107
N
26
B2236 - 12
Position Lamp Switch Circuit Short to Battery
111
N
27
B2236- 11
Position Lamp Switch Circuit short to Ground
115
N
28
C0040 – 11
Brake Pedal Switch Circuit short to Ground
119
N
29
C0040 – 12
Brake Pedal Switch Circuit short to Battery
123
N
30
B221A– 12
Headlamp On Signal – circuit short to battery
126
N
31
B221A – 11
Headlamp On Signal – Short to Ground
130
N
32
B225A– 14
Front Fog Lamp Relay– Short to Ground or
Open
134
N
33
B225A– 12
Front Fog Lamp Relay – Short to Battery
138
N
34
B222C– 11
Low Beam Relay– Short to Ground
142
N
35
B222C – 12
Low Beam Relay – Short to Battery
146
N
