Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.1
Date: 03 Mar 2017
Author: Body CoC
Page: 775 of 784
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
36
B2204– 11
Combined High Beam Circuit – Short to Ground
150
N
37
B2204 – 15
Combined High Beam – Short to Battery or
Open
154
N
38
B2224– 11
Left Position Lamps– Short to Ground
158
N
39
B2224 – 15
Left Position Lamps – Short to Battery or Open
Circuit
162
Y
5
40
B2247– 11
Right Position Lamps– Short to Ground
166
N
41
B2247– 15
Right Position Lamps – Short to Battery or Open
Circuit
170
Y
5
42
B221F – 11
Left Front Fog Lamp Circuit Short to Ground
174
N
43
B221F – 15
Left Front Fog Lamp Circuit – Short to Battery or
Open Circuit
178
N
44
B2242 – 11
Right Front Fog Lamp Circuit – Short to Ground
182
N
45
B2242 – 15
Right Front Fog Lamp Circuit – Short to Battery
or Open Circuit
186
N
46
B2227 – 11
Left Stop Lamp Circuit – Short to Ground
190
N
47
B2227 – 15
Left stop Lamp Circuit – Short to Battery or
Open Circuit
194
N
48
B224A – 11
Right Stop Lamp Circuit – Short to Ground
198
N
49
B224A – 15
Right stop Lamp Circuit – Short to Battery or
Open Circuit
202
N
50
B225E – 11
Left Reverse Lamp Circuit – Short to Ground
206
N
51
B225E – 15
Left Reverse Lamp Circuit – Short to Battery or
Open Circuit
210
N
52
B225F – 11
Right Reverse Lamp Circuit – Short to Ground
214
N
53
B225F – 15
Right Reverse Lamp Circuit – Short to Battery or
Open Circuit
218
N
54
B2229 – 11
Left Turn Indicator – Short to Ground
222
N
55
B2229 – 15
Left Turn Indicator – Short to Battery or Open
Circuit
226
N
56
B224C – 11
Right Turn Indicator – Short to Ground
230
N
