DTC Troubleshooting Guide for Nexon
Version: 1.1
Date: 21/06/2017
Author: E&E Chassis - ERC
Page: 16 of 156
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
U3006 - 17: Control Module Input Power “A” – Circuit Voltage above Threshold
Overview:
This fault will come in engine running condition only
Input Power "A" is the Voltage Supply from battery
ISO Code
U3006 – 17
Customer Symptom
No warning lamp, Reduced assistance
Fault Effects (On Vehicle)
Reduced Assistance
Lamp Status (If Any)
Warning Lamp OFF
Fault Detection Condition
If Battery(supply) voltage greater than 16V
Alternator voltage o/p is greater than 14.5V.
Normal Operating Condition
PSCM should provide assist if steering wheel is steered after
engine is cranked. Normal operating range:
ECU will awake from 6V to 18V
Full assistance is b/w 10V to 16V
Reduced assistance is b/w 8.7V to 10V
Probable Trouble Area
Fuse box
Battery Supply line
Alternator overcharging
Healing Condition
NA
Component Details:
NA
Preliminary Checks:
1. Voltage at the battery terminals should be greater than 11.5V and less than 16V.
2. PSCM power supply connector should have voltage between 11.5 to 16 volts for full assistance.
3. Check battery cable and PSCM connector terminals for damage.
4. Check PSCM ECU for pin bend/damage.
5. Alternator output voltage should be between 13.5 V to 14.5 V in engine running condition.
