C100D-4B - Pump Motor Flow rate- Over Temperature
Overview
ISO Code
C100D-4B
Customer Symptom
Warning Light Displayed
Fault Effects (On Vehicle)
None of the functionalities of ABS ECU are available.
Lamp Status (If Any)
Warning Light Displayed
Fault Detection Condition
Normal Operating Condition
ABS is functional between 10 to 16V
Probable Trouble Area
x
RFP actuation for longer than threshold time limit.
x
Overheat in RFP circuit.
Healing Condition
NA
Component Details -
NA
Preliminary Checks -
NA
