B192B – 24 :Proximity Sensor Rear Mid-LH Failure – Signal Stuck High
Overview:
Write up for the Related Sensor:-
Rear Mid-Left Sensor – This sensor is placed on mid left side of rear bumper. In park assist
function, sensors are used to determine proximity of an obstacle in a warning zone with respect to
rear bumper.
Pre-Check Points:
NO
ISO Code
992B-24
Customer Symptom
When user activates Park assist using Reverse
gear/PDC Fascia Switch/HU, Park assist functionality
will not be available and “critical fault” Screen will be
displayed on HU.
Fault Effects (On Vehicle)
Park Assist functionality will not available to the user.
Lamp Status (If Any)
No
Fault Detection Condition
1. When user activates Park assist using
Reverse gear/PDC Fascia Switch/HU, Park
assist functionality will not be available and
critical fault will be displayed on HU.
2. This DTC gets logged when rear mid left
sensor signal is stuck high.
Normal Operating Condition
When user activates park assist, sensor sends the
obstacle audio and visual zone information to the
Head Unit.
Probable Trouble Area
x
PDC ECU side Connector
x
Sensor side connectors
x
Wiring harness between PDC ECU and
sensor.
Healing Condition
None
