NEXON DIAGNOSTIC MANUAL

TML Park Distance Controller (PDC) ECU DTC

Troubleshooting guide for Nexon

Version: 0.2

Date: 08Jun17

Author:

Ravi Teja

Page: 108 of 123

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of

author.

DTC’s confirmation: -

After rectification, ensure the following points using TML diagnostic tool before handing over to

customer.

a) DTC should not be present in ECU memory.

Circuit Schematic

Diagram:-N.A

Component Location & Image: - N.A

Connector Location: N.A

Connector View & Information: -N.A

Inspection Method: - N.A
