U3007-17:- Control Module Input Power “B” – Circuit Voltage Above Threshold
ISO Code
U3007-17
Customer Symptom
Park assist will probably not function or will
function intermittently or partially.
Fault Effects (On Vehicle)
Cannot determine scope without knowledge of
power line applicability. Note that, Park Assist
system powered on IGN line.
Lamp Status (If Any)
NA
Fault Detection Condition
If Battery(supply) voltage greater than 16V
Alternator voltage o/p is greater than 14.5V.
Normal Operating Condition
Normal operation voltage range is 9V - 16V.
Normal operation means, that the sensors are
working, and the obstacle distance information is
sent out via CAN messages.
Operation voltage range for CAN communication
is 7V to 18V. Degraded CAN communication is
not allowed outside this range.
Probable Trouble Area
Vehicle electrical fault
Healing Condition
NA
Preliminary Checks:
1.
Voltage at the battery terminals should be greater than 16V
2.
Alternator output voltage should be between 13.5 V to 14.5 V in engine running
condition. If it is great than 14.5, do the below mentioned.
Flow Chart:
