P0328-15: Knock Sensor 1 Circuit High – Circuit Short to Battery or Open
Overview:
ISO Code
P0328-15
Customer Symptom
Permanent Ignition Retardation.Knock control is not active, Power loss due to
Ignition retardation
Fault Effects (On Vehicle)
1. No knock control active.
2. Permanent ignition retardation.
3. Engine damage can happen with bad fuel quality.
Lamp Status (If Any)
CE lamp ON after 5 drive cycle
Fault Detection Condition
This fault gets logged if the Knock Sensor positive Line or Negative line is short
Circuited to Battery and Engine is in Running Condition..
Normal Operating Condition
Healthy Wiring Harness connections between Knock Sensor and EMS ECU.
Probable Trouble Area
Wiring Harness Connections, Knock Sensor
Healing Condition
Engine Running Condition and after 1 drive Cycle
Fault permanent deletion
1. Clear DTC Command form Scan tool
2. Stack Over Flow.3. 40 warm up cycles.4. ECU Flashing.5. ECU Power-Fail
Component Details:
Knock Sensor consists of a piezoelectric element. Piezoelectric elements generate voltage when vibration or pressure
is applied to them. The Piezoelectric element in the knock Sensor is tuned to the Engine Knock Frequency.
Preliminary Checks:
1) Loose/ Damaged Connections between Sensor and EMS ECU.
2) Check for back out of pins at both Sensor connector and ECU connector.
3) Check for damage of pins at both Sensor connector and ECU connector.
4) Check the continuity from Sensor connector pins to the ECU pins.
