Diagnosis
Use multimeter to check for coil resistance across pin 1 and pin 2, which should be between 300 ohms to 420 ohms
1. ECU pin 213: +ve
2. ECU pin 201: -ve
3. Shield
Use TATA diagnostic tool to check for engine rpm during cranking.
