P0481-13: Radiator Fan High Speed Relay Control Circuit – Circuit Open
Overview:
ISO Code
P0481-13
Customer Symptom
Engine Heat up and seize and damage components.
Fault Effects (On Vehicle)
Radiator Fan will not run, Engine Heat up and seize and damage components.
Lamp Status (If Any)
CE Lamp ON after 1 drive cycle
Fault Detection Condition
This fault gets logged if the Radiator fan control pin of EMS ecu is Open
Circuited.
Normal Operating Condition
Healthy Wiring Harness connections between Radiator Fan relay and EMS
ecu, Relay Fully Operational, Healthy Wiring Harness connections from Relay
to Main Relay supply and Ground.
Probable Trouble Area
Improper Wiring Harness Connections, faulty Relay,
Healing Condition
Ignition key on and 1 drive cycle after fault rectification
Fault permanent Deletion
1. Clear DTC Command form Scan tool
2. Stack Over Flow.
3. 40 warm up cycles.
4. ECU Flashing.
5. ECU Power-Fail
Component Details:
Radiator fan is driven by EMS ecu via a relay, Radiator Fan will be On, when the EMS ecu energizes the coil of fan
relay.
Preliminary Checks:
1) Loose/ Damaged Connections between Fan Relay and EMS ecu.
2) Loose/ Damaged Connections between Fan Relay and Battery supply or Ground.
3) Check for back out of pins at ECU connector.
4) Check for damage of pins at ECU connector.
.
