Trouble Shooting:-
Step Checks
IF YES
IF NO
1.
Is there any rust/oxidization observed on Sensor Terminals Clean the Rust or
repair or replace
Go to Step 2
2.
Is there wiring harness electrical continuity between ECU
pins 137, 110, 104 & AC Pressure Sensor connector pins
1,2,3.
Go to Step 3
Establish continuity
by rectifying
harness
connections as per
the Circuit
schematic
3.
Are there any pins damaged at Sensor/EMS ECU
Connector
Replace the
connector or wiring
harness
Go to step 4
4
Are there any pins backed out from the Sensor/EMS ECU
Connector
Rectify/Replace
Connectors
Go to Step 5
5
Is Sensor Supply pin – 137 Short Circuited to GND/Battery Go to Step 6
Repair the harness
as per the
schematic
6
Is Sensor Signal Pin 110, Short Circuited to GND/Battery
Repair the harness
as per the schematic Go to Step 7
7
Is Sensor physically Damaged
Replace Sensor
Go to Step 8
8
Fault Still Persists?
Replcae Sensor and
then Fault still
persists then
Replace EMS ECU
Follow the steps
again for
reconfirmation
DTC’s confirmation:-
After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before
handing over to customer.
Turn On the AC and decrease the AC Set temperature step wise, Check whether the Parameter – AC Pressure
Sensor is increasing.
