P0532-21: A/C Refrigerant Pressure Sensor “A” Circuit Low
Overview:
ISO Code
P0533-21
Customer Symptom
AC will not function
Fault Effects (On Vehicle)
AC Pressure parameter value will be faulty, AC will not Function.Wrong
indication of AC pressure
Lamp Status (If Any)
CE lamp ON after 3 drive cycles
Fault Detection Condition
This fault gets logged if the AC Pressure Signal pin of EMS ECU is short
Circuited to ground.
Normal Operating Condition
Healthy Wiring Harness connections between EMS ECU and AC Pressure
Sensor.
Probable Trouble Area
Wiring Harness connections, Faulty Sensor
Healing Condition
Ignition On and after 1 driving cycle of fault rectification
Fault permanent Deletion
1. Clear DTC Command form Scan tool
2. Stack Over Flow.
3. 40 warm up cycles.
4. ECU Flashing.
5. ECU Power-Fail
Component Details:
AC pressure Sensor consists of a silicon chip mounted inside a reference chamber. On one side of the chip is the
reference chamber and on the other side is the pressure to be measured. The electrical resistance of the chip varies
with the variation of pressure.This change in resistance alters the voltage signal.
Preliminary Checks:
1) Loose/ Damaged Connections between Sensor and EMS ECU.
2) Check for back out of pins at both Sensor connector and ECU connector.
3) Check for damage of pins at both Sensor connector and ECU connector.
4) Check the continuity from Sensor connector pins to the ECU pins.
