After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before handing
over to customer.
x
Start the engine, in neutral gear and press the accelerator pedal fully (as quickly as possible) for engine to go
from Idle to fly up.
x
Stay at fly up for few seconds and suddenly release the accelerator for the engine to come back to idle.
x
Repeat the above cycle 3 to 4 times and check the DTC does not reappear.
Schematic:
EMS ECU
15
14
VRS+
VRS-
