P1606: Non Volatile Memory – CAN/KWP fault
Overview:
DTC Description as per ISO standard.
ECU non-volatile memory fault
.
ECU Pin Number
ECU internal
Customer Symptom
-
Fault Effects (On Vehicle)
No recovery action.
Lamp Status (If Any)
-
Fault Detection Condition
Non Volatile memory - CAN or KWP [ECU non-volatile memory fault] -
CAN / KWP fault. This DTC gets logged due to ECU internal NVM failure.
Normal Operating Condition
No faults related to NVM logged by EMS.
Probable Trouble Area
ECU, Grounding points, Wiring harness
Healing Condition
Clear the errors, Ignition OFF to ON, engine idle & fly-up condition
Component Details:
EMS ECU is an electronic controller which controls the Engine functionality by interfacing with various sensors, actuators
and other controllers (via CAN)
Preliminary Checks:
x
Check whether the customer voice / view about the issue is matching with the fault effects mentioned above. If
yes, go ahead with next steps. If not, check for other DTC’s presence.
x
Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to
earlier issue closure. Check for pin back out at EMS ecu connector or EGR valve connector.
x
Check whether the EMS is receiving Battery supply and Ground
x
Check whether the Battery is healthy
Trouble Shooting:
Step
Checks
IF YES
IF NO
1.
Check whether the EMS ECU is receiving supply and
Ground. Check especially the earthing points whether
they are properly connected after removing body paint.
Any problem found?
Go to step 2
Rectify wiring
harness
connections as
per schematic
2.
Check whether the battery is healthy
Go to step 3
Repair Battery
3
If fault still persists
Replace EMS ECU
Repeat above
procedure for
reconfirmation
