2: Preliminary Check
1. Check ECM is communicating with TML diagnostic tool or not.
2. If NO, then check for continuity in the vehicle ODB connector pin no. 7 and ECM side vehicle wiring
harness connector K line (pin 35) pin.
3. There should be continuity between below pins in the vehicle side wiring harness.
IPC CAN_H (pin. 6) to ECM CAN_H (Pin 19) and IPC CAN_L (pin. 5) to ECM CAN_L (Pin 18)
4.
Read IVN DTCs in ECM in IGN ON condition with TML diagnostic tool.
