OSPREY- Application
DTC Troubleshooting Data
Version: 4.0
Date: 10-02-2017
Prepared by: Mithipati Prasad
Checked by: G S Raju / Senthilnathan S
Page: 607 of 654
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
ECM Pin Details:
Pin No.
Pin Name
Description
19
CAN_H
CAN High
18
CAN_L
CAN Low
49
Ign
Ignition
12.31
Vbat
Supply Voltage Battery
9, 28
GND
Battery GND
