yϭϬϰ KƐƉƌĞLJ /ŶƐƚƌƵŵĞŶƚ ůƵƐƚĞƌ
d dƌŽƵďůĞƐŚŽŽƚŝŶŐ ĂƚĂ
sĞƌƐŝŽŶ͗ ϭ͘ϯ
ĂƚĞ͗ ϮϬͲDĂƌĐŚͲϭϳ
Author: Balaji / Amar /
Nitin / Umapathi /
Deepak
Page: 6 of 138
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
dĂďůĞ ŽĨ ŽŶƚĞŶƚƐ
B190B - 11:- Ambient Temperature Sensor Input Short To Ground --------------------------------------------------------9
B190B - 15:- Ambient Temperature Sensor Input Short To Battery or Open ------------------------------------------- 14
B1909 - 11:- Fuel Level Sensor Input Short To Ground---------------------------------------------------------------------- 19
B1909 - 15:- Fuel Level Sensor Input Short To Battery or Open----------------------------------------------------------- 23
B1938 - 06:- Vehicle Speed Sensor Algorithm Based Failure -------------------------------------------------------------- 27
B1939 - 86:- Vehicle Speed Signal output Implausible Signal Invalid ---------------------------------------------------- 31
B191C - 11:- Vehicle Speed Sensor Power Supply Output Short To Ground ------------------------------------------ 35
U1010 - 14:- Key In Signal Input Short To Ground or Open ---------------------------------------------------------------- 39
B1934 - 09:- Set Switch Stuck Button Component Failures ---------------------------------------------------------------- 42
B1935 - 09:- Mode Switch Stuck Button Component Failures-------------------------------------------------------------- 46
B1936 - 56:- Odometer Values missing From VICM (Immobilizer) for Learning --------------------------------------- 50
B1937 - 31:- Acknowledgement missing from VICM for Learning --------------------------------------------------------- 54
U100F - 06:- Ignition Power mode Input Algorithm Based Failures ------------------------------------------------------- 58
B191E - 11:- Illumination Dimming Level Output Short to Ground-------------------------------------------------------- 62
B191E - 12:- Illumination Dimming Level Output Short to Battery -------------------------------------------------------- 66
U3006 - 16:- Control Module Input Power “A” – Circuit Voltage below Threshold ------------------------------------- 70
U3006 - 17:- Control Module Input Power “A” – Circuit Voltage above Threshold------------------------------------- 74
U1604 – 55:- Control Module Configuration - not configured --------------------------------------------------------------- 78
B1912 -15:- Park Brake Warning Indicator Input - circuit short to battery or open------------------------------------- 81
B1912 -11:- Park Brake Warning Indicator - circuit short to ground ------------------------------------------------------- 81
B1911 -15:- Brake Fluid Warning Indicator Input - circuit short to battery or open ------------------------------------ 81
B1911 -11:- Brake Fluid Warning Indicator Input - circuit short to ground ----------------------------------------------- 81
B190F -15:- Driver Seat Belt Warning Indicator Input - circuit short to battery or open------------------------------- 81
B190F -11:- Driver Seat Belt Warning Indicator Input circuit short to ground ------------------------------------------- 81
B1917 -15:- Driver Door Ajar Warning Indicator Input- circuit short to battery or open ------------------------------- 81
B1917 -11:- Driver Door Ajar Warning Indicator Input- circuit short to ground------------------------------------------ 81
B191A -14:- Park Lamp Input (Position Lamp Input) – circuit short to ground or open ------------------------------- 81
B191A -12:- Park Lamp Input (Position Lamp Input) – circuit short to battery ------------------------------------------ 81
B1914 -12:- Turn Left Indicator Input - circuit short to battery -------------------------------------------------------------- 81
B1914 -14:- Turn Left Indicator Input - circuit short to ground or Open--------------------------------------------------- 81
B1915 -12:- Turn Right Indicator Input - circuit short to battery ------------------------------------------------------------ 82
