DTC’s confirmation:-
After rectification, ensure the following points using TML diagnostic tool before handing over to customer
.
a) Check whether BCM ECU is communicating with diagnostic Tool or not.
b) DTC should not be in ECU fault memory.
Circuit Schematic Diagram:-
N.A
Component Location & Image:-
N.A
Connector Location:-
N.A
Connector View & Information: -
